Power:/
Cut-out:/
Beam angle:/
CCT: /
Color: Sand white/Sand black
Installation: Track mounted
Don’t have a business email? Click here!
Don’t have a business email? Click here!
Overview
| Model |
ST2121-GU10 |
|---|---|
| Power |
/ |
| Beam Angle |
/ |
| Cut-Out |
/ |
| Installation |
Track mounted |
| Dimension |
3-phase / 1-phase |
| CCT |
/ |
| CRI |
/ |
| Luminous Flux |
/ |
| LED |
/ |
| Color |
Sand white/Sand black |
| Surface finish |
Powder Coating |
| Material |
Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
220-240VAC 50/60Hz |
| Vf & If |
/ |
| Model |
SD8201060R |
|---|---|
| Power |
15W |
| Beam Angle |
15°/24°/36°/55° |
| Cut-Out |
Φ60mm |
| Installation |
Recessed |
| Dimension |
Φ67xH93mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
1200lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 350mA |
| Model |
SD052075S |
|---|---|
| Power |
12W ,15W ,18W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
75x75mm |
| Installation |
Recessed |
| Dimension |
82×82×H115mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
960lm-1440lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Csting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 300mA/350mA/450mA |
| Model |
SD8111200R |
|---|---|
| Power |
50W |
| Beam Angle |
24°/40°/55° |
| Cut-Out |
Φ200mm |
| Installation |
Recessed |
| Dimension |
Φ215×H105mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
3700lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 1200mA |
| Model |
SD7201030RLS-L |
|---|---|
| Power |
7W |
| Beam Angle |
24°/36°/45° |
| Cut-Out |
Φ30mm |
| Installation |
Recessed |
| Dimension |
Φ50xH90mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA80/RA90 |
| Luminous Flux |
350lm |
| LED |
Bridgelux |
| Color |
Sand white/Sand black |
| Surface finish |
Powder Coating |
| Material |
Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
220-240VAC 50/60Hz |
| Vf & If |
30-42V 150mA |
| Model |
SD7202040RS-L |
|---|---|
| Power |
7W |
| Beam Angle |
24°/36°/45° |
| Cut-Out |
Φ40mm |
| Installation |
Recessed |
| Dimension |
Φ46xH90mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA80/RA90 |
| Luminous Flux |
350lm |
| LED |
Bridgelux |
| Color |
Sand white/Sand black |
| Surface finish |
Powder Coating |
| Material |
Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
220-240VAC 50/60Hz |
| Vf & If |
30-42V 150mA |
