Power:35W
Cut-out: Φ115-125mm
Beam angle:15°/24°/36°/60°
CCT: 2700K/3000K/3500K/4000K
Color: White / Black / Custom
Installation: Recessed
Don’t have a business email? Click here!
Don’t have a business email? Click here!
Overview
| Model |
SC6082115R-R |
|---|---|
| Power |
35W |
| Beam Angle |
15°/24°/36°/60° |
| Cut-Out |
Φ115-125mm |
| Installation |
Recessed |
| Dimension |
Φ138×H105mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
3100lm / 3500lm(HE) |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 800mA |
| Model |
SD052075R |
|---|---|
| Power |
12W ,8W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
Φ75mm |
| Installation |
Recessed |
| Dimension |
Φ82×H79mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
640lm-960lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 200mA/300mA |
| Model |
SD041075S |
|---|---|
| Power |
8W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
75x75mm |
| Installation |
Recessed |
| Dimension |
82×82×H88mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
640lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Csting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 200mA |
| Model |
SG80501037S |
|---|---|
| Power |
3W |
| Beam Angle |
24°/30°/45° |
| Cut-Out |
37x37mm |
| Installation |
Recessed |
| Dimension |
45x45x50mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
180lm |
| LED |
Origin Bridgelux 3535 |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
2-4V 700mA |
| Model |
SS811075RH |
|---|---|
| Power |
15W |
| Beam Angle |
20°/40° |
| Cut-Out |
/ |
| Installation |
Surface Mounted |
| Dimension |
Φ75×H152mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
1200lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 350mA |
| Model |
ST6141W |
|---|---|
| Power |
20W ,30W |
| Beam Angle |
90° |
| Cut-Out |
/ |
| Installation |
3-phase / 1-phase |
| Dimension |
33×33xL800mm |
| CCT |
2700K/3000K/4000K/5000K/6500K |
| CRI |
RA80 ,RA90 |
| Luminous Flux |
20W @930 1300lm 65lm/W(S) |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 500/750mA |
