Power: 8W/12W
Cut-out: 75x75mm
Beam angle: 15°/24°/36°/55°
CCT: 2700K/3000K/3500K/4000K
Color: White / Black / Custom
Installation: Recessed
Don’t have a business email? Click here!
Don’t have a business email? Click here!
Overview | Model |
SD042075SL |
|---|---|
| Power |
12W ,8W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
75x75mm |
| Installation |
Recessed |
| Dimension |
110×110×H93mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
640lm-960lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Csting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 200mA/300mA |
| Model |
ST3023 |
|---|---|
| Power |
12W ,8W |
| Beam Angle |
15°/24°/36°/55° |
| Cut-Out |
Φ70mm |
| Installation |
Recessed |
| Dimension |
Φ54xH130mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
640LM/960LM |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 180mA/300mA |
| Model |
ST3121W |
|---|---|
| Power |
20W |
| Beam Angle |
15°/24°/36°/50° |
| Cut-Out |
/ |
| Installation |
3-phase / 1-phase |
| Dimension |
Φ60×L165mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
80Ra/90Ra |
| Luminous Flux |
1800lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 500mA |
| Model |
SD043068R |
|---|---|
| Power |
15W |
| Beam Angle |
Wall Wash |
| Cut-Out |
Φ68mm |
| Installation |
Recessed |
| Dimension |
Φ75xH90mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
800LM |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 350mA |
| Model |
SD051068R |
|---|---|
| Power |
12W ,15W ,18W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
Φ68mm |
| Installation |
Recessed |
| Dimension |
Φ75×H98mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
960lm-1440lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 300mA/350mA/450mA |
| Model |
SS8081602S |
|---|---|
| Power |
4x12W |
| Beam Angle |
100° |
| Cut-Out |
/ |
| Installation |
Surface Mounted |
| Dimension |
160*160*H78mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA80/RA90 |
| Luminous Flux |
4x960lm |
| LED |
Origin Bridgelux SMD |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 4x300mA |
