ST5101W
Power: 30W
CCT: 2700K/3000K/3500K/4000K
Beam angle: 15°/24°/36°/50°
Color: White / Black / Custom
Installation: 3-phase / 1-phase
Cut-out:/
Don’t have a business email? Click here!
Don’t have a business email? Click here!
Overview
| Model |
ST5101W |
|---|---|
| Power |
30W |
| Beam Angle |
15°/24°/36°/50° |
| Cut-Out |
/ |
| Installation |
3-phase / 1-phase |
| Dimension |
Φ80 x 120mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
90Ra/95Ra |
| Luminous Flux |
2800lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 750mA |
| Model |
ST5111W |
|---|---|
| Power |
30W |
| Beam Angle |
15°/24°/36°/55° |
| Cut-Out |
/ |
| Installation |
3-phase / 1-phase |
| Dimension |
Φ80 x 120mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
90Ra/95Ra |
| Luminous Flux |
3100lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 750mA |
| Model |
SD041075R |
|---|---|
| Power |
12W ,15W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
Φ75mm |
| Installation |
Recessed |
| Dimension |
Φ82×H98mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
960lm/1200lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Csting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 300mA/350mA |
| Model |
SG80510037S-S |
|---|---|
| Power |
22W |
| Beam Angle |
24°/30°/45° |
| Cut-Out |
/ |
| Installation |
Surface Mounted |
| Dimension |
268x35x70mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
1800LM |
| LED |
Origin Bridgelux 3535 |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
27-33V 700mA |
| Model |
SD8031120R |
|---|---|
| Power |
25W |
| Beam Angle |
15/24/36/45° |
| Cut-Out |
120x120mm |
| Installation |
Recessed |
| Dimension |
140×140×H129mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
2100lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 600mA |
| Model |
SC6082115R-L |
|---|---|
| Power |
35W |
| Beam Angle |
20°/24°/30° |
| Cut-Out |
Φ115-125mm |
| Installation |
Recessed |
| Dimension |
Φ138×H105mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
3200lm / 3800lm(HE) |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 800mA |
