Power: 22W
Cut-out: /
Beam angle: 24°/30°/45°
CCT: 2700K/3000K/3500K/4000K
Color: White / Black / Custom
Installation: Surface Mounted
Mini and Linear shape grid light for limited place and special applications.
Available in 1 / 2 / 5 / 10 / 15 LEDs model type.
Wall Wash / Adjustable / Trimless / Surface Mounted version available.
CCT 2700K / 3000K / 4000/ 6000K available, CRI 80 / 90 optional.
Don’t have a business email? Click here!
Don’t have a business email? Click here!
Overview
| Model |
SG80510037S-S |
|---|---|
| Power |
22W |
| Beam Angle |
24°/30°/45° |
| Cut-Out |
/ |
| Installation |
Surface Mounted |
| Dimension |
268x35x70mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
1800LM |
| LED |
Origin Bridgelux 3535 |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
27-33V 700mA |
| Model |
SD8111115R |
|---|---|
| Power |
25W |
| Beam Angle |
20°/24°/36°/45° |
| Cut-Out |
Φ115mm |
| Installation |
Recessed |
| Dimension |
Φ131×H75mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
1900lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 600mA |
| Model |
SD041075R |
|---|---|
| Power |
12W ,15W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
Φ75mm |
| Installation |
Recessed |
| Dimension |
Φ82×H98mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
960lm/1200lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Csting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 300mA/350mA |
| Model |
SD8111075R |
|---|---|
| Power |
12W |
| Beam Angle |
18°/24°/30°/40° |
| Cut-Out |
Φ75mm |
| Installation |
Recessed |
| Dimension |
Φ85×H54mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
800lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 300mA |
| Model |
SD8071080R |
|---|---|
| Power |
12W |
| Beam Angle |
30°/45° |
| Cut-Out |
Φ80mm |
| Installation |
Recessed |
| Dimension |
Φ96×H75mm |
| CCT |
3000K ,4000K ,6000K |
| CRI |
80Ra ,90Ra |
| Luminous Flux |
960lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 300mA |
| Model |
SD011030HR-C |
|---|---|
| Power |
3W |
| Beam Angle |
20°/30°/40° |
| Cut-Out |
Φ30mm |
| Installation |
Recessed |
| Dimension |
Φ34xH34.5mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
150LM |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Spray Painting |
| Material |
Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
15-21V 150mA |
