Power: 25W
Cut-out:Φ68mm
Beam angle: 15°/24°/36°/55°
CCT: 2700K/3000K/3500K/4000K
Color: White / Black / Custom
Installation: Recessed
Non avete un'e-mail aziendale? Clicca qui!
Non avete un'e-mail aziendale? Clicca qui!
Overview | Model |
SD044068R |
|---|---|
| Power |
25W |
| Beam Angle |
15°/24°/36°/55° |
| Cut-Out |
Φ68mm |
| Installazione |
Recessed |
| Dimension |
Φ75xH112mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
2200LM |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 600mA |
| Model |
SD051068R |
|---|---|
| Power |
12W ,15W ,18W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
Φ68mm |
| Installazione |
Recessed |
| Dimension |
Φ75×H98mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
960lm-1440lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 300mA/350mA/450mA |
| Model |
SD8281120R |
|---|---|
| Power |
30W |
| Beam Angle |
15°/24°/36°/55° |
| Cut-Out |
Φ120mm |
| Installazione |
Recessed |
| Dimension |
Φ138×H74mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
2400lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 700mA |
| Model |
SD8261060R |
|---|---|
| Power |
12W |
| Beam Angle |
24°/36°/55° |
| Cut-Out |
Φ60mm |
| Installazione |
Recessed |
| Dimension |
Φ70×H100mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
1200lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 350mA |
| Model |
SD041075R |
|---|---|
| Power |
12W ,15W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
Φ75mm |
| Installazione |
Recessed |
| Dimension |
Φ82×H102mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
960lm/1200lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Csting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 300mA/350mA |
| Model |
SD8161165R |
|---|---|
| Power |
20W |
| Beam Angle |
80° |
| Cut-Out |
Φ165mm |
| Installazione |
Recessed |
| Dimension |
Φ185×H93mm |
| CCT |
3000K ,4000K ,6000K |
| CRI |
80Ra ,90Ra |
| Luminous Flux |
1600lm |
| LED |
Origin Bridgelux SMD |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 500mA |
