Power:35W
Cut-out: Φ115-125mm
Beam angle: 20°/24°/30°
CCT: 2700K/3000K/3500K/4000K
Color: White / Black / Custom
Installation: Recessed
Don’t have a business email? Click here!
Don’t have a business email? Click here!
Overview | Model | SC6082115R-L |
|---|---|
| Power | 35W |
| Beam Angle | 20°/24°/30° |
| Cut-Out | Φ115-125mm |
| Installation | Recessed |
| Dimension | Φ138×H105mm |
| CCT | 2700K/3000K/3500K/4000K |
| CRI | RA90/RA95 |
| Luminous Flux | 3200lm / 3800lm(HE) |
| LED | Origin Bridgelux COB |
| Color | White / Black / Custom |
| Surface finish | Powder Coating |
| Material | Die-casting aluminum |
| IP Rate | IP20 |
| Input Voltage | AC220-240V |
| Vf & If | 30-42V 800mA |
| Model | SD044068R |
|---|---|
| Power | 25W |
| Beam Angle | 15°/24°/36°/55° |
| Cut-Out | Φ68mm |
| Installation | Recessed |
| Dimension | Φ75xH112mm |
| CCT | 2700K/3000K/3500K/4000K |
| CRI | RA90/RA95 |
| Luminous Flux | 2200LM |
| LED | Origin Bridgelux COB |
| Color | White / Black / Custom |
| Surface finish | Powder Coating |
| Material | Die-casting aluminum |
| IP Rate | IP20 |
| Input Voltage | AC220-240V |
| Vf & If | 30-42V 600mA |
| Model | SG80510037S-L |
|---|---|
| Power | 22W |
| Beam Angle | 24°/30°/45° |
| Cut-Out | 285x45mm, 285x50mm |
| Installation | Recessed |
| Dimension | 280*91*60mm |
| CCT | 2700K/3000K/3500K/4000K |
| CRI | RA90/RA95 |
| Luminous Flux | 1800LM |
| LED | Origin Bridgelux 3535 |
| Color | White / Black / Custom |
| Surface finish | Powder Coating |
| Material | Die-casting aluminum |
| IP Rate | IP20 |
| Input Voltage | AC220-240V |
| Vf & If | 27-33V 700mA |
| Model | SD051075S |
|---|---|
| Power | 12W, 15W, 18W |
| Beam Angle | 15°, 24°, 36°, 55° |
| Cut-Out | 75x75mm |
| Installation | Recessed |
| Dimension | 82×82×H111mm |
| CCT | 2700K, 3000K, 3500K, 4000K |
| CRI | 90Ra, 95Ra |
| Luminous Flux | 960lm-1440lm |
| LED | Origin Bridgelux COB |
| Color | White / Black / Custom |
| Surface finish | Powder Coating |
| Material | Die Casting Aluminum |
| IP Rate | IP20/IP54 |
| Input Voltage | AC220-240V |
| Vf & If | 30-42V 300mA/350mA/450mA |
| Model | SD043075R |
|---|---|
| Power | 8W |
| Beam Angle | Wall Wash |
| Cut-Out | Φ75mm |
| Installation | Recessed |
| Dimension | Φ83xH90mm |
| CCT | 2700K, 3000K, 3500K, 4000K |
| CRI | 90Ra, 95Ra |
| Luminous Flux | 800LM |
| LED | Origin Bridgelux COB |
| Color | White / Black / Custom |
| Surface finish | Powder Coating |
| Material | Die Casting Aluminum |
| IP Rate | IP20 |
| Input Voltage | AC220-240V |
| Vf & If | 30-42V 350mA |
| Model | SD8292145R |
|---|---|
| Power | 45W |
| Beam Angle | 15°/24°/36°/55° |
| Cut-Out | Φ145mm |
| Installation | Recessed |
| Dimension | Φ168×H179mm |
| CCT | 2700K, 3000K, 3500K, 4000K |
| CRI | 90Ra, 95Ra |
| Luminous Flux | 3600lm |
| LED | Origin Bridgelux COB |
| Color | White / Black / Custom |
| Surface finish | Powder Coating |
| Material | Die Casting Aluminum |
| IP Rate | IP20 |
| Input Voltage | AC220-240V |
| Vf & If | 30-42V 1050mA |
