Power:25W
Cut-out: Φ100mm
Beam angle: 24°/30°/40°
CCT: 2700K/3000K/3500K/4000K
Color: White / Black / Custom
Installation: Recessed
Har du ingen e-postadress för ditt företag? Klicka här!
Har du ingen e-postadress för ditt företag? Klicka här!
Overview | Model |
SC6082100R-AR |
|---|---|
| Power |
25W |
| Beam Angle |
24°/40°/60° |
| Cut-Out |
Φ100mm |
| Installation |
Recessed |
| Dimension |
Φ110×H90mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
2600lm / 3000lm(HE) |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 600mA |
| Model |
SC6032175R |
|---|---|
| Power |
2x12W |
| Beam Angle |
15°/24°/30° |
| Cut-Out |
90×175mm |
| Installation |
Recessed |
| Dimension |
185×100×H120mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
90Ra/95Ra |
| Luminous Flux |
2x960lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 2x300mA |
| Model |
SG80515037S-W |
|---|---|
| Power |
35W |
| Beam Angle |
Wall Wash |
| Cut-Out |
403x37mm |
| Installation |
Recessed |
| Dimension |
411x45x50mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
1800LM |
| LED |
Origin Bridgelux SMD |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 700mA |
| Model |
SD051075R |
|---|---|
| Power |
12W ,15W ,18W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
Φ75mm |
| Installation |
Recessed |
| Dimension |
Φ82×H98mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
960lm-1440lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Csting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 300mA/350mA/450mA |
| Model |
SG80510037S-A |
|---|---|
| Power |
22W |
| Beam Angle |
24°/30°/45° |
| Cut-Out |
285x50mm |
| Installation |
Recessed |
| Dimension |
291x59x50mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
1800LM |
| LED |
Origin Bridgelux 3535 |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
27-33V 700mA |
| Model |
SG80505037S-S |
|---|---|
| Power |
12W |
| Beam Angle |
24°/30°/45° |
| Cut-Out |
/ |
| Installation |
Surface Mounted |
| Dimension |
136x35x70mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
900LM |
| LED |
Origin Bridgelux 3535 |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
12-18V 700mA |
