Power:20W
Cut-out: /
Beam angle: 24°/32°/55°
CCT: 2700K/3000K/3500K/4000K
Color: White / Black / Custom
Installation: Surface Mounted
Don’t have a business email? Click here!
Don’t have a business email? Click here!
Overview
| Model |
SS815110R |
|---|---|
| Power |
20W |
| Beam Angle |
24°/32°/55° |
| Cut-Out |
/ |
| Installation |
Surface Mounted |
| Dimension |
Φ110×H110mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
2000LM |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 500mA |
| Model |
ST5101W |
|---|---|
| Power |
30W |
| Beam Angle |
15°/24°/36°/50° |
| Cut-Out |
/ |
| Installation |
3-phase / 1-phase |
| Dimension |
Φ80 x 120mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
90Ra/95Ra |
| Luminous Flux |
2800lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 750mA |
| Model |
SG80502037S |
|---|---|
| Power |
6W |
| Beam Angle |
24°/30°/45° |
| Cut-Out |
67x37mm |
| Installation |
Recessed |
| Dimension |
75x45x50mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
360lm |
| LED |
Origin Bridgelux 3535 |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
4-8V 700mA |
| Model |
SD042055R |
|---|---|
| Power |
8W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
Φ55mm |
| Installation |
Recessed |
| Dimension |
Φ60×H80mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
640lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 180mA |
| Model |
SD8141100R |
|---|---|
| Power |
6W |
| Beam Angle |
90° |
| Cut-Out |
Φ100mm |
| Installation |
Recessed |
| Dimension |
Φ115×H48mm |
| CCT |
3000K ,4000K ,6000K |
| CRI |
80Ra ,90Ra |
| Luminous Flux |
480lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 150mA |
| Model |
SC6082100R-L |
|---|---|
| Power |
25W |
| Beam Angle |
24°/30°/40° |
| Cut-Out |
Φ100mm |
| Installation |
Recessed |
| Dimension |
Φ110×H90mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
2450lm / 2700lm(HE) |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 600mA |
