SG80501037S
Power: 3W
Cut-out:37x37mm
Beam angle: 24°/30°/45°
CCT: 2700K/3000K/3500K/4000K
Color: White / Black / Custom
Installation: Recessed
Har du ingen e-postadress för ditt företag? Klicka här!
Har du ingen e-postadress för ditt företag? Klicka här!
Overview | Model |
SG80501037S |
|---|---|
| Power |
3W |
| Beam Angle |
24°/30°/45° |
| Cut-Out |
37x37mm |
| Installation |
Recessed |
| Dimension |
45x45x50mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
180lm |
| LED |
Origin Bridgelux 3535 |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
2-4V 700mA |
| Model |
SG80703145S |
|---|---|
| Power |
23Wx3 ,32Wx3 |
| Beam Angle |
15/24/36/50° |
| Cut-Out |
450x145mm |
| Installation |
Recessed |
| Dimension |
465x160x100mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
3x 2550lm / 3000lm(HE) @23W |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 600mAx3/800mAx3 |
| Model |
SS815072S |
|---|---|
| Power |
12W |
| Beam Angle |
20°/40°/60° |
| Cut-Out |
/ |
| Installation |
Surface Mounted |
| Dimension |
90×90×H90mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
1000LM |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 300mA |
| Model |
SD041068R |
|---|---|
| Power |
8W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
Φ68mm |
| Installation |
Recessed |
| Dimension |
Φ75×H75mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
640lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 200mA |
| Model |
SD042075SL |
|---|---|
| Power |
8W |
| Beam Angle |
15° ,24° ,36° ,55° |
| Cut-Out |
75x75mm |
| Installation |
Recessed |
| Dimension |
110×110×H93mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
640lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Csting Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 200mA |
