Power: 15W
Cut-out:Φ120mm
Beam angle: 60°
CCT: 3000K/4000K/6000K
Color: White / Black / Custom
Installation: Recessed
Non avete un'e-mail aziendale? Clicca qui!
Non avete un'e-mail aziendale? Clicca qui!
Overview | Model |
SD8131120R |
|---|---|
| Power |
15W |
| Beam Angle |
60° |
| Cut-Out |
Φ120mm |
| Installazione |
Recessed |
| Dimension |
Φ130×H68mm |
| CCT |
3000K ,4000K ,6000K |
| CRI |
80Ra ,90Ra |
| Luminous Flux |
1350/1800lm |
| LED |
Origin Bridgelux SMD |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 350mA |
| Model |
SC6033260R |
|---|---|
| Power |
3x12W |
| Beam Angle |
15°/24°/30° |
| Cut-Out |
90×260mm |
| Installazione |
Recessed |
| Dimension |
270×100×H120mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
90Ra/95Ra |
| Luminous Flux |
3x960lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Casting Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 3x300mA |
| Model |
SG80701145S |
|---|---|
| Power |
23W ,32W |
| Beam Angle |
15/24/36/50° |
| Cut-Out |
145x145mm |
| Installazione |
Recessed |
| Dimension |
160x160x100mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
2550lm / 3000lm(HE) @23W |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 600mA/800mA |
| Model |
SD011030HR-C |
|---|---|
| Power |
3W |
| Beam Angle |
20°/30°/40° |
| Cut-Out |
Φ30mm |
| Installazione |
Recessed |
| Dimension |
Φ34xH34.5mm |
| CCT |
2700K ,3000K ,3500K ,4000K |
| CRI |
90Ra ,95Ra |
| Luminous Flux |
150LM |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Spray Painting |
| Material |
Aluminum |
| IP Rate |
IP20/IP54 |
| Input Voltage |
AC220-240V |
| Vf & If |
15-21V 150mA |
| Model |
SD044068RL |
|---|---|
| Power |
15W |
| Beam Angle |
15°/24°/36°/55° |
| Cut-Out |
Φ68mm |
| Installazione |
Recessed |
| Dimension |
Φ110xH90mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
1350LM |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die-casting aluminum |
| IP Rate |
IP20 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 350mA |
| Model |
SD8271145R |
|---|---|
| Power |
35W |
| Beam Angle |
15°/24°/36°/55° |
| Cut-Out |
Φ145mm |
| Installazione |
Recessed |
| Dimension |
Φ158×H96mm |
| CCT |
2700K/3000K/3500K/4000K |
| CRI |
RA90/RA95 |
| Luminous Flux |
2800lm |
| LED |
Origin Bridgelux COB |
| Color |
White / Black / Custom |
| Surface finish |
Powder Coating |
| Material |
Die Csting Aluminum |
| IP Rate |
IP20/IP65 |
| Input Voltage |
AC220-240V |
| Vf & If |
30-42V 800mA |
